FUSION LIGHT EN-C INTERMEDIATE-ADVANCED

FUSION LIGHT EN-C INTERMEDIATE-ADVANCED

$4,800.00 USD
$4,800.00 USD
Sale Sold out
Shipping calculated at checkout.
Color
Size



https://www.flowparagliders.com.au/fusion-light/



Included in delivery: Concertina bag, Inner bag, Repair kit, Stickers



Fusion Light is the light version of the Fusion. It is available in sizes S, M and ML. Size XS is in development and it will be available early 2022.

Built extensively with Porcher Skytex 27g and light weight dyneema risers, the Fusion Light is livelier, lighter, more compact and has a more direct handling and feel.

We’ve managed to improve the speed range and the overall performance slightly, making our EN C glider even better. The fun factor and real performance of this glider is truly amazing. Like it’s original brother, Fusion Light is a game changer!

We have introduced a pulley on the floating B riser, which gives a true 2-liner feel as well as lighter rear riser control, integrating the hybrid 3-2 line layout in harmony and efficiency.

We believe the Fusion Light will be the perfect glider for many adventures, hike & fly missions or just the perfect companion for your next flight.

We are happy that the Fusion Light is certified, as it is the favourite glider of our team pilots, and it can now be appreciated and enjoyed by intermediate pilots who like the practicality of a 3 liner glider and the efficiency of a purebred 2 liner racer.



HYBRID 3 TO 2-LINE LAYOUT

Fusion Light rear riser steering is a game changer in performance gains for an EN C class.

Allowing the pilot to fly at speed through active thermic air. Direct feedback and millisecond reaction time to catch collapses and steer the glider while keeping the same top speed whilst improving glide ratio.

The concept is the same as 2-liners, and the biggest advantage besides direct feel through the toggles is its ability to keep “nose up” and pitch stability maintaining the solidity throughout the whole glide. Either on a thermic ridge run or under a cloud street, the Fusion Light allows the pilot to fly at full bar with confidence and solidity.

Rather than distorting the airfoil the direct rear riser steering causes a real change in AoA allowing the pilot to keep flying at full speed retaining its energy which therefore converts bubbles into lift.



TECHNICAL DATA

Tamanho Área Plana (m²) Área Projetada (m²) Envergadura Plana (m) Envergadura Projetada (m) Razão de Aspecto Razão de Aspecto Projetada Corda Máxima (m) Número de Células Peso da Asa (kgs) Peso de Decolagem (kgs) Certificação
S 22.95 19.56 12.07 9.73 6.35 4.86 2.38 68 3.6 72-92 LTF/EN C
M 24.45 20.89 12.48 10.06 6.35 4.86 2.45 68 3.8 80-103 LTF/EN C
ML 26.3 22.47 12.94 10.43 6.35 4.86 2.54 68 3.95 92-115 LTF/EN C



MATERIALS

Componente Material/Fabricante
CANOPY
Upper Surface Front Skytex 32 - Porcher
Upper Surface Back Skytex 27 Classic 2 - Porcher
Bottom Surface Skytex 27 Classic 2 - Porcher
Supported Ribs Skytex 27 hard - Porcher
Unsupported Ribs Skytex 27 hard - Porcher
Profile Reinforcement 2.5/1.8/ Nylon rods - Porcher
SUSPENSION LINES
Upper Cascades
Edelrid 8000U 130/090/070/050kg - EDELRID
Edelrid 9200 030kg - EDELRID
Middle Cascades
Edelrid 8000U 190/130/090/070/050kg - EDELRID
Edelrid 9200 030kg - EDELRID
Main Lines
Edelrid 8000U 360/190/130/050kg - EDELRID
Liros DSL 140kg - LIROS GmbH
RISERS
Soft Shackles Dyneema Rope - Liros
Riser Webbing 8mm zero stretch Dyneema webbing - Liros
Pulleys Pulleys Ronstan ball bearing - Ronstan



ADVANCE INTERNAL STRUCTURE TENSIONING – AIST



SHORT STRUCTURAL NYLON RODS

Strategically placed plastic rods of different stiffness and thickeners to give optimum rigidity to the canopy.



Fusion’s plastic rods are mostly of a short length allowing an easy fold without the use of a dedicated folding pillow. Ultimately allowing an uncomplicated folding procedure.



HYBRID 3 TO 2-LINE LAYOUT

The hybrid 3-2 line layout brings drastic drag reduction in comparison
to the traditional 3 lines layout. Ultimately translating to increased gains in performance.
  • Better glide
  • More solidity
  • More efficiency
  • Higher top-end speed
  • Increased solidity at higher speeds

ALIGHTED UNDISTURBED AIR FLOW

The Fusion was designed in a way where every cell is aligned to true airflow so there is less disturbance by the inherent billowing effect found on paragliders.



The canopy twist and washout on the wingtips further reduce drag and improve the lift coefficients and aerodynamics on the Fusion.



PITCH STABLE SHARK NOSE AIRFOIL

Our solid shark nose profile is a pitch stable airfoil which means:

  • Fewer oscillations
  • More efficient glides
  • Solidity at higher speeds
  • Higher Comfort

OPTIMIZED INTERNAL STRUCTURE

Each cell and diagonals were structurally dimensioned and thoroughly computer analyzed to offer the most suitable chord and span-wise sail tension.



The result is a canopy with less attachment points but more taught and rigid offering just enough flex characteristics to give the ideal feedback.

A well-tensioned sail is especially important at higher speeds to improve solidity and resistance against collapses.



COLOURS
